Methanol and ethanol distillation equipment
Methanol and ethanol distillation equipment
This device is suitable for dilute alcohol recovery in pharmaceutical, food, light industry, chemical industry and other industries. It is also suitable for the distillation of other solvents such as methanol. According to the user's requirements, this device can30℃About 10% dilute alcohol is distilled to90℃-95℃For alcohol, the higher the alcohol content requirement of the finished product, the reflux ratio can be increased, but the output will be reduced accordingly.WThe type can also be used for distillation of methanol and the like.WThe type is intermittent,ZWThe type is connected.
|
model |
Tower diameter (mm) |
30°-40°Feed production capacity |
60°-80°Feed production capacity |
|
90° |
<95° |
90° |
<95° |
|
W-200 |
¢200 |
35 |
26 |
45 |
36 |
|
W-300 |
¢300 |
80 |
61 |
100 |
80 |
|
W-400 |
¢400 |
150 |
120 |
180 |
140 |
|
W-500 |
¢500 |
230 |
185 |
275 |
220 |
|
W-600 |
¢600 |
335 |
270 |
400 |
320 |
|
ZW-200 |
¢200 |
95 |
>95° 60 |
110 |
>95° 80 |
|
ZW-300 |
¢300 |
200 |
120 |
240 |
165 |
|
ZW-400 |
¢400 |
360 |
230 |
420 |
300 |
